LED Flood Lights With Modular Bricks for High Mast High Bay Lighting

Click to view original image
Unit Price: Price Hidden by Seller
Term: Ex-works
MOQ: 100 pcs
Lead Time: 30 days
Origin: China
Last Updated: 2017-11-14 00:31
Views: 268
Send inquiry
Company Information
Jinghong Lighting designs and manufactures high-performance lighting products for the commercial, industrial and institutional markets. The company has been dedicated to providing the lighting industry with the highest quality, most reliable and c... [more]


Product Details
  • Type: Modular Design
  • LED: LED Array
  • LED Brand: LUXEON
  • Power: 101-120W,121-150W,151-200W,201-250W,251-300W
  • Input Voltage: 100-305VAC
  • Luminous Flux: 10000-11999 lm,12000-14999 lm,15000-19999 lm,80000 lm+
  • Luminous Efficacy: 120-129 lm/W
  • CRI: 80 min.
  • Driver: Constant Current
  • Driver Brand: Mean Well
  • Dimmability: 1-10VAC,PWM,DALI Dimming
  • Features:
  • Special Application:
  • Light Distribution:
  • Mount: Yoke
  • Certification: CE,RoHS
  • L70 Life: 50,000 Hours
  • IP Rating: IP66
  • Warranty: 5 Years
Jinghong's modular LED flood lights are designed to deliver exceptional performance and visual comfort, dramatically reduce energy consumption and virtually eliminate maintenance. The high output LED flood luminaire is designed to deliver high lumen packages with precise optical control for sports arenas, airports, loading docks, tunnels, road and building construction sites, golf courses, warehouses, industrial facilities, exhibition halls, aircraft hangars, shipyards, and more. Highly efficient LEDs with highly efficacy of 115-130 lumens per watt delivers unmatched performance in a rugged design with superior optical and thermal management systems to bring across many benefits of utilizing solid state lighting technology in industrial, outdoor and sports lighting applications. The LED modules are assemblied on a high thermal conductivity aluminum PCB with a thickness of 1.6mm. Available in multi-beam angles -  40°, 80°, 120°, 30*70°, 70*140°, the flexibility of photometric design allows for multiple light distributions to meet a wide range of specific lighting requirements. Each LED brick comes with a constant current, high efficiency LED driver with active power factor correction, short circuit, over current, over Voltage and ver temperature protection. The LED floodlight features a rugged die cast aluminum housing with a corrosion and UV resistant powder coat finish, providing an efficient thermal path to the heat sink assembly, ensuring low LED junction temperature, reliability and sustained lumen performance for an extended product life. The modular configuration adds greater flexibility and scalability. Available in six wattage options including 100W, 150W, 200W, 400W, 500W, 600W, 1000W. Our product is IP66 rated for installations where moisture, dirt, dust, corrosion and vibration may be present.
modular-led-flood
modular-led-flood-1
